• FOR Li-POLYMER  LiMnO Protect Parameter(3.6V/3.7V)
  • Single cell battery overcharge protect voltage : 4.21-4.29 V
  • Single cell battery overcharge  protect recover voltage : 4.14-4.24 V
  • Overcharge protect delay : 1.5-2.5S
  • Single cell battery over-discharge  protect voltage : 2.72-2.88 V
  • Single cell battery over-discharge  protect recover voltage : 2.9-3.1 V
  • Over charge protective current:100A
  • Over discharge protective current:100A
  • Over-discharge protect delay : 0.5-1.5S
  • Temperature protect : Yes,have Temperature control interface.
  • Disconnect protect : Yes
  • Shortage protect : Yes
  • Shortage delay : 100-600 uS
  • Shortage protect recover mode: Off load release.
  • Contact discharge current:80A
  • Synopline discharge current:60A
  • Charging current:60A
  • balance function:yes
  • Ampere balance (Current) : 60MA
  • Current balance accuracy : 4.14-4.24V

Write a review

Note: HTML is not translated!
    Bad           Good
Captcha

5S BMS Lithium Battery Protection Circuit Board 21V 100A

  • Product Code: 0249
  • Availability: In Stock
  • 5.90€
